Product attributes

1

Rated working pressure

PN

1.0-1.6Mpa

2

Test pressure

Shell

1.5-2.4Mpa

seal

1.1-1.76Mpa

3

working temperature

T

0-100℃

4

Applicable media

Freshwater, sea water, air, weak acids and bases, etc.

NO.

Name

Texture of material

NO.

Name

Texture of material

1

阀体

DI

6

Lubricating sleeve

PTFE

2

下阀轴

SS410

7

Upper valve shaft

SS410

3

密封带

PTFE

8

Connecting bolt

45#、Stainless steel

4

垫圈

45#steel

9

Actuator

Aluminium alloy

5

阀板

PTFE+WCB

10

DN

ΦD

4-Φd1

H1

H2

H3

L1

L2

L3

L4

DN40

106.00

22

65

211.0

92.0

33.5

30

71.5

147

DN50

123.00

22

70

233.5

107.5

42

32

83

168

DN65

142.00

22

81

248.5

107.5

45

47

83

168

DN80

154.50

23

96

270.5

119.5

45

65

95

184

154.50

23

DN100

183.00

27

109

299.7

128.7

52.1

91

103

204

DN125

212.50

25

123

323.5

136.5

55

112

108.5

262

DN150

240.00

24

137

361.0

153.0

56

146

121.5

268

DN200

295.00

24

168

422.0

175

61

194

142

301

296.00

25

DN250

356.00

31

203

477.0

192.0

66

242

152

390

DN300

407.00

25

246

533.0

217

77

292

174

458

432.00

32

DN350

460.00

23

279

617.0

260

77

325

206

525

470.00

26

DN400

515.00

26

300

667.0

285

87

380

226

532

525.00

30

DN450

565.00

26

320

728.0

319

105

428

260

602

585.00

30

DN500

620.00

26

363

824.0

356

130

474

294

722

650.00

33

DN600

725.00

20-Φ30

449

900.0

380

152

573

336

760

770.00

20-Φ36

DN700

840.00

24-Φ30

501

623.0

164

673

840.00

24-Φ36

DN800

950.00

24-Φ33

681

581.0

190

770

950.00

24-Φ39

DN900

1050.00

28-Φ33

733

639.0

204

838

1050.00

28-Φ39

DN1000

1160.00

28-Φ36

820

705.0

215

940

1170.00

28-Φ42

DN1200

1380.00

32-Φ39

942

846.0

350

1101

1390.00

32-Φ48
