Model：
|
NO |
Product attributes |
| |
|
1 |
Rated working pressure |
PN |
1.0-1.6Mpa |
|
2 |
Test pressure |
|
1.5-2.4Mpa |
|
Seal |
1.1-1.76Mpa | ||
|
3 |
working temperature |
T |
0-100℃ |
|
4 |
Applicable media |
Freshwater, sea water, | |
|
NO |
name |
Texture of material |
NO |
name |
Texture of material |
|
1 |
O-ring seal |
NBR |
7 |
Seat backrest |
phenolic resin |
|
2 |
Anti-backlash clip spring |
50#Manganese Steel |
8 |
Valve plate |
QT450 nickel plating, QT450 nylon coating, aluminum bronze, 304, 316, 316L, 2507, 1.4469, 1.4529 |
|
3 |
Backstop ring |
45# Galvanizing |
9 |
Backstop rod |
UPVC、45# |
|
4 |
Round gasket |
45# Galvanizing |
10 |
Lower Valve Shaft |
304, 316, 416 stainless steel, 45 # carbon steel |
|
5 |
Lubricating sleeve |
Teflon |
11 |
Seat rubber |
EPDM, NBR, FTFE, silica gel, fluorine gel |
|
6 |
Upper valve shaft |
304、316、416stainless steel, 45 # carbon steel |
12 |
valve body |
HT200, QT450, Stainless Steel, Cast Steel |
|
DN |
ΦD1/D2 |
4-Φd1/d2 |
n-Φd3 |
ΦD1 |
H1 |
H2 |
H3 |
ΦD2 |
M*M |
L1 |
L2 |
|
DN32 |
85.00 |
14 |
4-∮6 |
60 |
48.0 |
98.0 |
11 |
36 |
9*9 |
32 |
30 |
|
100.00 |
18 | ||||||||||
|
DN40 |
106.00 |
22 |
4-∮7 |
72 |
65.0 |
119.0 |
11 |
50 |
11*11 |
33.5 |
30 |
|
DN50 |
120.00 |
21, |
4-∮7 |
72 |
70.0 |
125.5 |
11 |
50 |
11*11 |
42 |
32 |
|
125.00 |
21 | ||||||||||
|
DN65 |
139.50 |
21 |
4-∮7 |
72 |
81.0 |
140.5 |
11 |
50 |
11*11 |
45 |
47 |
|
145.00 |
21 | ||||||||||
|
DN80 |
152.50 |
21 |
4-∮7 |
72 |
92.5 |
150.5 |
11 |
50 |
11*11 |
45 |
65 |
|
160.00 |
21 | ||||||||||
|
DN100 |
175.00 |
21 |
4-∮10 |
92 |
109.5 |
170.5 |
14 |
70 |
14*14 |
52.1 |
91 |
|
190.50 |
21 | ||||||||||
|
DN125 |
210.00 |
23 |
4-∮10 |
92 |
124.0 |
187.0 |
17 |
70 |
17*17 |
55 |
112 |
|
220.00 |
23 | ||||||||||
|
DN150 |
240.00 |
24 |
4-∮10 |
92 |
139.5 |
208.5 |
17 |
70 |
17*17 |
56 |
146 |
|
250.00 |
24 | ||||||||||
|
DN200 |
295.00 |
24 |
4-∮12 |
125 |
169.5 |
246.5 |
22 |
102 |
22*22 |
61 |
194 |
|
298.50 |
26 | ||||||||||
|
DN250 |
350.00 |
26 |
4-∮12 |
125 |
201.0 |
285.0 |
22 |
102 |
22*22 |
66 |
242 |
|
362.00 |
26 | ||||||||||
|
DN300 |
400.00 |
26 |
4-∮14 |
150 |
237.0 |
316.0 |
27 |
125 |
27*27 |
77 |
292 |
|
432.00 |
26 | ||||||||||
|
DN350 |
460.00 |
23 |
4-∮14 |
150 |
279.0 |
357.0 |
27 |
125 |
27*27 |
77 |
325 |
|
470.00 |
26 | ||||||||||
|
DN400 |
515.00 |
26 |
4-∮18 |
175 |
300.0 |
382.0 |
40 |
140 |
36*36 |
87 |
380 |
|
525.00 |
30 | ||||||||||
|
DN450 |
565.00 |
26 |
4-∮18 |
175 |
320.0 |
409.0 |
40 |
140 |
36*36 |
105 |
428 |
|
585.00 |
30 | ||||||||||
|
DN500 |
620.00 |
26 |
4-∮22 |
210 |
363.0 |
468.0 |
50 |
165 |
46*46 |
130 |
474 |
|
650.00 |
33 | ||||||||||
|
DN600 |
725.00 |
20-Φ30 |
4-∮22 |
210 |
449.0 |
520.0 |
50 |
165 |
46*46 |
152 |
573 |
|
770.00 |
20-Φ36 | ||||||||||
|
DN700 |
840.00 |
24-Φ30 |
8-∮18 |
300 |
501.0 |
623.0 |
70 |
254 |
64*64 |
164 |
673 |
|
840.00 |
24-Φ36 | ||||||||||
|
DN800 |
950.00 |
24-Φ33 |
8-∮18 |
300 |
681.0 |
581.0 |
70 |
254 |
64*64 |
190 |
770 |
|
950.00 |
24-Φ39 | ||||||||||
|
DN900 |
1050.00 |
28-Φ33 |
8-∮18 |
300 |
733.0 |
639.0 |
80 |
254 |
74*74 |
204 |
838 |
|
1050.00 |
28-Φ39 | ||||||||||
|
DN1000 |
1160.00 |
28-Φ36 |
8-∮18 |
300 |
820.0 |
705.0 |
80 |
254 |
74*74 |
215 |
940 |
|
1170.00 |
28-Φ42 | ||||||||||
|
DN1200 |
1380.00 |
32-Φ39 |
8-∮22 |
350 |
942.0 |
846.0 |
90 |
298 |
84*84 |
350 |
1101 |
|
1390.00 |
32-Φ48 |
