Model：
|
NO |
Product attributes | ||
|
1 |
Rated working pressure |
PN |
1.0-1.6Mpa |
|
2 |
Test pressure |
Shell |
1.5-2.4Mpa |
|
Seal |
1.1-1.76Mpa | ||
|
3 |
working temperature |
T |
0-100℃ |
|
4 |
Applicable media |
Freshwater, sea water, | |
|
NO |
Name |
|
NO |
Name |
|
|
1 |
handwheel |
cast iron |
8 |
Upper valve shaft |
45#、304、316、416stainless steel |
|
2 |
Connecting bolt |
45 #, Stainless Steel |
9 |
Seat rubber |
EPDM、NBR |
|
3 |
O-ring |
NBR |
10 |
Valve plate |
QT450 nickel plating, QT450 nylon coating, aluminum bronze, 304, 316, 316L, 2507, 1.4469, 1.4529 |
|
4 |
Anti-backlash clip spring |
50#Manganese Steel |
11 |
Backstop rod |
UPVC、45# |
|
5 |
Backstop ring |
45#Galvanizing |
12 |
Lower Valve Shaft |
304、316、416不锈钢 45#carbon steel |
|
6 |
Round gasket |
45#Galvanizing |
13 |
valve body |
Cast iron, stainless steel, cast steel |
|
7 |
Lubricating sleeve |
Teflon |
|
DN |
ΦD |
ΦD1 |
n-Φd |
H1 |
H2 |
L1 |
L2 |
D0 |
|
DN40 |
110.00 |
150 |
4-Φ18 |
76 |
202 |
110 |
148 |
136 |
|
DN50 |
125.00 |
165 |
4-Φ18 |
81 |
208 |
110 |
148 |
136 |
|
DN65 |
145.00 |
185 |
4-Φ18 |
96 |
212 |
114 |
148 |
136 |
|
DN80 |
160.00 |
200 |
4-Φ18 |
98 |
218 |
116 |
148 |
136 |
|
160.00 |
200 |
8-Φ18 | ||||||
|
DN100 |
180.00 |
220 |
8-Φ18 |
111 |
241 |
129 |
148 |
136 |
|
DN125 |
210.00 |
250 |
8-Φ18 |
128 |
247 |
142 |
148 |
136 |
|
DN150 |
240.00 |
285 |
8-Φ22 |
143 |
266 |
142 |
148 |
136 |
|
DN200 |
295.00 |
340 |
8-Φ22 |
172 |
309 |
154 |
193 |
263 |
|
295.00 |
340 |
12-Φ22 | ||||||
|
DN250 |
350.00 |
395 |
12-Φ22 |
199 |
341 |
167 |
193 |
263 |
|
355.00 |
405 |
12-Φ26 | ||||||
|
DN300 |
400.00 |
445 |
12-Φ22 |
231 |
377 |
180 |
210 |
263 |
|
410.00 |
460 |
12-Φ26 | ||||||
|
DN350 |
460.00 |
505 |
16-Φ22 |
253 |
405 |
192 |
210 |
263 |
|
470.00 |
520 |
16-Φ26 | ||||||
|
DN400 |
515.00 |
565 |
16-Φ26 |
266 |
466 |
218 |
301 |
400 |
|
525.00 |
580 |
16-Φ30 | ||||||
|
DN450 |
565.00 |
615 |
20-Φ26 |
299 |
558 |
224 |
220 |
300 |
|
585.00 |
640 |
20-Φ30 | ||||||
|
DN500 |
620.00 |
670 |
20-Φ26 |
327 |
609 |
231 |
317 |
300 |
|
650.00 |
715 |
20-Φ33 | ||||||
|
DN600 |
725.00 |
780 |
20-Φ30 |
385 |
692 |
270 |
334 |
300 |
|
770.00 |
840 |
20-Φ36 | ||||||
|
DN700 |
840.00 |
895 |
24-Φ30 |
456 |
771 |
293 |
280 |
400 |
|
840.00 |
910 |
24-Φ36 | ||||||
|
DN800 |
950.00 |
1015 |
24-Φ33 |
487 |
819 |
318 |
280 |
400 |
|
950.00 |
1025 |
24-Φ39 | ||||||
|
DN900 |
1050.00 |
1115 |
28-Φ33 |
555 |
933 |
328 |
330 |
400 |
|
1050.00 |
1125 |
28-Φ39 | ||||||
|
DN1000 |
1160.00 |
1230 |
28-Φ36 |
621 |
983 |
413 |
330 |
400 |
|
1170.00 |
1255 |
28-Φ42 | ||||||
|
DN1200 |
1380.00 |
1455 |
32-Φ39 |
775 |
1245 |
473 |
440 |
430 |
|
1390.00 |
1485 |
32-Φ48 |
