NO.

Product attributes

1

Rated working pressure

PN

1.0-1.6Mpa

2

Test pressure

Shell

1.5-2.4Mpa

Seal

1.1-1.76Mpa

3

working temperature

T

0-100℃

4

Applicable media

Freshwater, sea water, air, weak acids and bases, etc.

NO.

Name

Texture of material

NO.

Name

Texture of material

1

Handle

Aluminium alloy

9

Lubricating sleeve

PTFE

2

Connecting top wire

45#

10

Upper valve shaft

304, 316, 416 stainless steel 45 # carbon steel

3

Gear plate

45#

11

Seat backrest

phenolic resin

4

Connecting bolt

45 #, Stainless Steel

12

Valve plate

QT450 nickel plating, QT450 nylon coating, aluminum bronze, 304, 316, 316L, 2507, 1.4469, 1.4529

5

O-ring

NBR

13

Backstop rod

UPVC, 45#

6

Anti-backlash clip spring

50 # Manganese Steel

14

Lower Valve Shaft

304, 316, 416 stainless steel 45 # carbon steel

7

Backstop ring

45 # Galvanizing

15

Seat rubber

EPDM, NBR, FTFE, silica gel, fluorine gel

8

Round gasket

45 # Galvanizing

16

valve body

HT200, QT450, Stainless Steel, Cast Steel
